F1

The F1 is a new 4G badge recorder launched by bestar Technology. It combines 4G HD video transmission, voice group dispatch, 4G/WIFI, H.265 encoding, 2K HD recording, Bluetooth, and pure hardware single Beidou positioning modules. Working with the MCS8 multimedia communication system platform, it enables remote dispatch and command for mobile individuals. It can be widely used in industries like commerce, taxation, electricity, railways, and finance.
Schedule a demo Email product details
Highlights of F1
  • HD touchscreen
    2.3-inch HD IPS touchscreen, supports multi-touch
  • 4G scheduling
    4G full network compatibility, sending live HD footage back to the control center for real-time visual command and dispatch
  • HD recording
    Supports multiple resolutions like 2K/1080P, and uses ultra-low bitrate transmission with dual-stream hardware encoding design
Specification of F1
Overview
CPUMT6769  8 Cores CPU  64 bit, 2.0GHz
Operating systemAndroid 12.0（AOSP）
Storage capacity2GB+16GB (optional 4+64 / 4+256)
Display screen2.3-inch HD touch screen (480*200)
Number of cameras1 Camera
Main camera perspectiveHorizontal viewing angle ≥ 100° Distortion ≤ 5%
Video compression formatH.264/H.265
Video resolution2560×1440/30fps，1920×1080/30fps，1280×720/30fps，640×480/30fps
Photo resolution64 MP
4GLTE FDD: B1/B3/B5/B8；LTE TDD: B34/B38/B39/B40/B41
Wi-FiSupport 2.4G/5G，IEEE802.11 a/b/g/n/ac
Blue toothBT5.0
NFCSupport (optional)
PositioningSupports GPS, Beidou, and GLONASS; supports standalone Beidou
Charging dockNot supported
Battery capacity1450mAH
FlashSupport, 1 flash
Red and blue warning lightsSupport
Laser light

Support (optional)

How to wear

Pin, magnetic

TF card slotDetachable, single TF card slot (memory/encryption card), supports up to 512GB
SIM card slotBuilt-in, Nano card
Dimensions (HxWxD)87.5 x 33.5 x 16.2mm
Weight60g (main unit)



* The product images, specifications, features, and accessories shown on this page may be adjusted as technology and production improve. To ensure you get the correct product and compatible accessories, please contact the Bestar sales team for the latest information before placing an order. Bestar reserves the right to change product details without prior notice.
